3D print Stadion Poljud
A free, printable model of the stadium and the parkland, ring road and buildings around it, generated from real map data in your browser.
Free, in your browser. Exports a slicer-ready 3MF.
About Stadion Poljud
Stadion Poljud, officially Gradski stadion u Poljudu, meaning City Stadium in Poljud, is a multi-purpose ground in Split, Croatia. It stands in the Poljud neighborhood, which belongs to the city district of Spinut, and it opened in September 1979. Hajduk Split football club has played there since 1979. It originally held 55,000 spectators, and the capacity rose to 62,000 in the 1980s. Seats were fitted in the 1990s, which cut the capacity to 33,987.
Croatian architect Boris Magaš designed the seashell-like stadium. Its roof structure spans 206 by 47 meters, and the stands offer views of nearby hills and forests, modeled after ancient Greek theaters. Nineteen cabins hang from the west roof shell. Seven are for TV reporters, and the rest hold cameras, a central referee station, the photo finish, the scoreboard and audio control. A catwalk through the roof gives access to the cabins and to 630 Philips lights on the roof's brim and its inner side.
The 1990 European Athletics Championships and the 2010 IAAF Continental Cup were both held at Poljud, and it was refurbished before the 2010 event, with a new tartan track. The inner ground holds a 105 by 68 meters football pitch with eight running tracks around it. The electronic music festival Ultra Europe took place at the stadium from 2013 until 2019. The stadium gained official recognition as cultural heritage in November 2015.
How it prints
Make this print opens the generator on a 600 m square around the landmark. Buildings print at close to true scale, so the landmark grows with the print size.
| Print size | Landmark height | Scale |
|---|---|---|
| 160 mm default | 12 mm | 1:3,750 |
| 200 mm | 15 mm | 1:3,000 |
| 256 mm | 19 mm | 1:2,344 |
-
North
-
East
-
South
-
West
- A sweeping shell roof
- The seashell-shaped roof sweeps over one stand as a thin, curved sheet. Print slowly with layers of 0.12 to 0.16 mm to keep its curved edge smooth; Print friendly adapts the thinnest parts to the print scale.
- Slender struts under the roof
- Slim angled supports run under the roof along one side. Full detail keeps all of them, which suits a larger print or a fine nozzle.
- One piece with the ground
- Stadion Poljud is joined to the ground in the exported file, and the four-side check found no floating parts, so nothing needs gluing.
- Pick the detail for your nozzle
- In the Buildings settings, set Landmark detail to Print friendly to adapt thin parts and small details to the print scale. Full detail keeps every modeled feature, for larger prints or a finer nozzle.
- Colors
- Buildings, roads, water and ground arrive as separate filament slots in the 3MF. Stadion Poljud takes the building color.
- File format
- You get a 3MF for Bambu Studio, OrcaSlicer or PrusaSlicer. Any of them can save it as STL if you need one.
About this model
Stadion Poljud is one of more than 2,300 landmark models in Mini Skyline. They are made with AI, and each one is checked from four sides in its real surroundings before release. Everything around it is built from OpenStreetMap and Overture map data. If you would rather print the shape from map data, turn off Landmark models in the Buildings settings.
Common questions
Is there a Stadion Poljud STL I can download?
Mini Skyline builds the file for you in your browser and exports 3MF, which every major slicer opens. If you need an STL, open the 3MF in your slicer and export it from there.
How big can I print it?
Any print size from 40 mm across. Stadion Poljud grows with the print: about 12 mm tall on the default 160 mm print. For a model larger than your printer bed, Project Mode splits the area into tiles.
Is it free?
Yes. Generation runs in your browser, with no account and nothing behind a paywall.
