3D print the Chilehaus
A free, printable model of the Chilehaus in Hamburg's Kontorhaus District, with the surrounding streets and buildings, generated from real map data in your browser.
-
North
-
East
-
South
-
West
- On a 160 mm print
- 13 mm
- Scale
- 1:3,750
13 mm tall on a 160 mm print
Make this print opens the generator on a 600 m square around the landmark. Buildings print at close to true scale, so the landmark grows with the print size.
- Corner and upper floors
A block of this kind carries fine edges along its sharp corner and recessed upper floors. Print friendly adapts thin parts and small details to the print scale; Full detail keeps every modeled feature for a larger print or a finer nozzle.
- One piece with the ground
The Chilehaus is joined to the ground in the exported file, and the four-side check found no floating parts, so nothing needs gluing.
- Pick the detail for your nozzle
In the Buildings settings, set Landmark detail to Print friendly to adapt thin parts and small details to the print scale. Full detail keeps every modeled feature, for larger prints or a finer nozzle.
- Colors
Buildings, roads, water and ground arrive as separate filament slots in the 3MF. The Chilehaus takes the building color.
- File format
You get a 3MF for Bambu Studio, OrcaSlicer or PrusaSlicer. Any of them can save it as STL if you need one.
About the Chilehaus
The Chilehaus, a ten-story office block in Hamburg's Kontorhaus District, is an example of the Brick Expressionism of the 1920s. It occupies a site of roughly 6,000 m2 (1.5 acres) and spans Fischertwiete Street. The German architect Fritz Höger designed it, and it was finished in 1924. In 2015 UNESCO added the Kontorhaus District, Chilehaus included, to its World Heritage list.
Its top recalls a ship's prow, and at the junction of the Pumpenstrasse and Niedernstrasse two facades converge at a very narrow angle. Strong vertical elements, recessed upper stories and a curved facade on the Pumpenstraße give the large block a sense of lightness, and the building is best seen from the east. The structure is reinforced concrete, built with 4.8 million dark Oldenburg bricks. Difficult ground required reinforced-concrete pilings 16 meters deep.
The shipping magnate Henry B. Sloman commissioned the building; he had made his fortune in the saltpeter trade with Chile, which gave the house its name. The sculptor Richard Kuöhl provided the sculptural elements for the facade and the staircases. Because the site lies close to the Elbe River, the cellar was specially sealed, and the heating equipment sits in a caisson that can float inside the building if it floods.
About this model
The Chilehaus is one of more than 4,400 landmark models in Mini Skyline. They are made with AI, and each one is checked from four sides in its real surroundings before release. Everything around it is built from OpenStreetMap and Overture map data. If you would rather print the shape from map data, turn off Landmark models in the Buildings settings.
