3D print Shum Yip Upperhills Tower 1
A free, printable model of Shum Yip Upperhills Tower 1, with the surrounding city of Shenzhen, generated from real map data in your browser.
-
North
-
East
-
South
-
West
- Real height
- 388 m
- On a 160 mm print
- 106 mm
- Scale
- 1:3,750
388 m of Shum Yip Upperhills Tower 1, 106 mm on your shelf
Make this print opens the generator on a 600 m square around the landmark. Buildings print at close to true scale, so the landmark grows with the print size.
- Tall, slender tower
The tower is tall and narrow at the default size. Slow the print and use cooling on the upper floors, and choose 0.12–0.16 mm layers to keep its edges crisp.
- One piece with the ground
Shum Yip Upperhills Tower 1 is joined to the ground in the exported file, and the four-side check found no floating parts, so nothing needs gluing.
- Pick the detail for your nozzle
In the Buildings settings, set Landmark detail to Print friendly to adapt thin parts and small details to the print scale. Full detail keeps every modeled feature, for larger prints or a finer nozzle.
- Colors
Buildings, roads, water and ground arrive as separate filament slots in the 3MF. Shum Yip Upperhills Tower 1 takes the building color.
- File format
You get a 3MF for Bambu Studio, OrcaSlicer or PrusaSlicer. Any of them can save it as STL if you need one.
About Shum Yip Upperhills Tower 1
Shum Yip Upperhills Tower 1, known in Chinese as 深业上城大厦 1, is a supertall skyscraper in Shenzhen, Guangdong, China. It stands 388.1 meters (1,273.3 ft) tall, has 80 floors above ground, and was completed in 2020. Construction began on February 12, 2014. Its structural system is unusual among supertall towers with mega-columns.
The tower uses a novel structural system, the Ladder Core System. Instead of linking the outer mega columns to the core only at mechanical floors, it ties them to the reinforced concrete core on every floor. In the office portion it also leaves out the supplemental gravity columns found in other supertall towers with mega-columns. On each face the corner framing beside the mega-columns cantilevers 8.5 m, forming a balanced cantilever that creates a 28.5 m clear span between the two mega-columns. The result is a column-free middle span on every face.
About this model
Shum Yip Upperhills Tower 1 is one of more than 4,400 landmark models in Mini Skyline. They are made with AI, and each one is checked from four sides in its real surroundings before release. Everything around it is built from OpenStreetMap and Overture map data. If you would rather print the shape from map data, turn off Landmark models in the Buildings settings.
